Analysis Modes
Four specialized workspaces, each optimized for a different calibration workflow. Choose your mode, CalibraLogic adapts.
Diagnostics
DTC analysis & fault troubleshooting
Your first stop when a car comes in. Paste a DTC code or describe symptoms — get root cause analysis, sensor plausibility checks, and step-by-step troubleshooting.
Global DTC Registry
Component Health
Log Analysis
Data log interpretation & monitoring
Upload datalogs or describe what you see. AI identifies knock events, boost deviations, AFR anomalies, and timing issues across your traces.
CSV, HPL, DAT, LOG
Pattern Matching
Map Analysis
Calibration map evaluation & tuning
Ask about specific maps, get value recommendations, understand axis relationships. AI cross-references verified technical documentation automatically.
Technical Documentation Integration
Interpolation Logic
Firmware Logic
Firmware disassembly & reverse engineering
Deep firmware analysis. Understand torque structures, priority chains, injection strategies. For Ghidra users and advanced engineers.
ASM / Decompilation
Control Loop Logic
Modes organize your workflow.
Engines power the analysis.
Every mode is a tailored UI interface that routes your data to the optimal AI engine for that specific engineering task.
Which Mode Should I Use?
| Metric | Diagnostics | Log Analysis | Map Analysis | Firmware Logic |
|---|---|---|---|---|
| Typical Input | DTC codes, symptoms | Datalogs, CSV | Binary files, map data | Firmware binary, decompiled code |
| Complexity | Low | Medium | Medium-High | High |
| Speed of Result | Seconds | Seconds | Minutes | Minutes |
